Self-Locking Design: Features a self-locking trapezoidal threaded spindle with an end-stop body, ensuring the jack holds its position securely under heavy static loads without drifting.
Highly Versatile: Includes a 12mm centering hole for various pads, allowing for numerous adaptations. The coupling pad (P-6) allows stacking for increased height capacity on models U11-2 and U11-3.
Robust Construction: Manufactured from heat-treated Carbon Steel with a blackened finish for high strength and corrosion resistance.
Broad Load Range: Engineered to support heavy industrial components, with static load capacities ranging from 12 kN up to 350 kN.
| Code | Range (H1-H2 mm) | Base Dia (D1 mm) | Cap Dia (DC mm) | Max Static Load (kN) | Weight (kg) |
| U11-1 | 40 – 50 | 32 | 32 | 12 | 0.230 |
| U11-2 | 50 – 70 | 50 | 50 | 60 | 0.600 |
| U11-3 | 70 – 100 | 50 | 50 | 60 | 0.800 |
| U11-4 | 100 – 140 | 70 | 65 | 100 | 2.500 |
| U11-5 | 140 – 210 | 80 | 70 | 165 | 4.560 |
| U11-6 | 190 – 300 | 98 | 80 | 350 | 9.100 |
