Twin Guide Super Value Machinist’s Vice, Swivel Base Code No. U301 NS

Name: Twin Guide Super Value Machinist’s Vice, Swivel Base Code No. U301 NS
SKU: 13330
Rating: 5.00 (1 reviews)

Rated 5.00 out of 5 based on 1 customer rating

Features

Twin Guide Super Value Machinist’s Vice, Fixed Base, body made of Ductile Iron (Unbreakable Steel Body).
Unbreakable steel nut is provided.
Jaws of special carbon steel properly heat treated grinded and Serrated to ensure a fast non slip grip.
Spindle screw is fine pitched made of alloy steel.
Swivel base rotates 360º and can be fixed at any position.

The slide is provided with Double Rib to ensure Smoot

Number	0	0	1	2	3	4	5	6	8
SIZE IN INCHES	2.1/4	2.1/2	3	3.1/2	4	4.1/2	5	6	8
Width of jaws in mm	60	65	75	90	100	115	125	150	200
Opening of jaws in mm	60	65	80	110	110	130	160	170	240
Depth of jaws in mm	42	48	58	65	68	80	85	93	100
Height Overall	97	105	125	137	155	170	182	200	225
Width Overall	100	100	110	137	160	165	170	180	220
Length Overall	205	205	250	290	355	370	425	485	540
Weight Approx. in kgs.	3.6	3.6	6	9.5	15	16.5	21.5	27.5	44
