Specifications…..
| Jaw Width (mm) | Jaw Depth (mm) | Jaw Opening (mm) | Overall Height (mm) | Weight (kg) |
| 80 (3″) | 45 | 75 | 70 | 4.5 |
| 100 (4″) | 60 | 115 | 85 | 8.0 |
| 150 (6″) | 60 | 155 | 100 | 15.5 |
Slot Size: 10 mm (3″) / 13 mm (4″ & 6″)
Unique Drill Press Vise Code No: U317
Key Features
-
Durable Body: Main body manufactured from close-grain cast iron, providing excellent structural rigidity and vibration dampening.
-
Versatile Jaw Design: Equipped with special steel-ground jaws featuring an integrated “V” groove, which allows for the secure and accurate holding of round workpieces (shafts, pipes, or rods).
-
High-Strength Lead Screw: Features a special steel lead screw designed for smooth operation and consistent, powerful clamping force.
-
Secure Mounting: Provided with four “T” slots located on both sides, ensuring a rigid grip on the drill press table to prevent movement during operation.
